city view with snow topped mountains in background
Written by David Dengler

Drones for Architecture

Episode 1: Veritas

As an architect, you may wonder if can you leverage drone technology in your current workflow? The answer is – Yes! Let’s look at how and where it makes sense. Drones can provide meaningful data throughout the entire process – from concept through completion.

Read More
Tunnel scan to BIM model
Written by Garrett Maldoon

Point Cloud to Revit Model Automation

When you need to capture as-built conditions there are multiple methodologies to consider. A few of the high-tech options growing in popularity are LiDAR scanning & Photogrammetry to assist in the collection of data. Both methods produce point clouds with vectorized data which means everything can be measured.

Read More
JDI Matrice 200 drone flying above pine trees with mountains in the background
Written by David Dengler

Drone Subcontracting

Outsourcing Drone Services for Efficiency and Cost Savings

Can an architect design his own structural system or HVAC system? Yes, he can. Can the same architect also go out to the site and dig the foundations and nail the framing together? Sure. He can do all of those things. But, is it really the best use of his time and abilities?

Read More
Dollar bill folded to read "We need a revolution" referring to detailing BIM: no lines necessary
Written by Jay Zallan

Detailing BIM: No Lines Necessary

Revit is not a drafting software.

Revit is not AutoCAD.

CAD* is not BIM (*as understood in normal conversation).

CAD* processes Do Not Work In BIM.

Any part of “traditional” or drafting-based approaches will fail in BIM.

Yes, any and every… if you can find one that works let me know @JayZallan on the tweeties…

We are going to focus on Detailing; one area where value can be generated if applied comprehensively; namely Using Detail Components and never Lines.

If you are going to callout, or point to, or list in any way, or even look at now or sometime in the future; Use Detail Components for items (never lines), and Tags and/or Keynotes in place of text, to provide “the words and numbers.”
Toward a Zen of Revit: Less Text = Less Mistakes

Details using lines, arcs, circles & text are a disaster, but disasters land on a continuum and there are worse “details in Revit blunders:”

  • Linking .dwgs in (10% to 30% longer project time)
  • Importing .dwgs in (15% to 40% longer project time)
  • Converting .dwg linework to Revit linework (10% to 25% longer project time).

I understand that most offices have many hundreds of standard details or typical details that are used… With that in mind the workflow entails recreating (yep, recreate) all of the existing, ‘appropriate’ details in Revit natively, using only Detail Components for items that will be called out and specified… then use Keynotes and Tags instead of text when detailing. The goal will be overall and long term saving of time, money and will raise project and informational quality. The quality of the data “between” details using this setup will payoff for years, literally… not doing it will add hidden losses to every project, also for years.

Assess | Plan | Create | Validate

OK onto those details sans lines…
How-To Create a Line Based Family

FWIW: I am not talking about lines within ‘sketch modes’ etc. either; in fact the detail component that we will be creating in this posting will ultimately use a line (though at the family level, so it doesn’t count lol)… The logic is: ‘When the line-based family is used to make a detail component, it may work and look like a simple line but it has become far more than that… it becomes a ‘Data Enlightened Object.’

In the example below we are looking at a waterproofing membrane (image 1) to be specified.
-Perhaps even create and use Detail Components for generic items such as “WALL PER PLANS”, etc., when no wall is needed 3 dimensionally… Oh and YES, the wall below would NOT have the waterproofing membrane on the exterior of the finish… I merely use it as example.

Image 1

As described above, in the stead of using lines and pointing to them with non associative text we will rather build Line Based Detail Components or Detail Component line based (Image 2), as the family template is so named (depending on what year you read this).











Image 2 (Revit Circa 1842)

The procedures to ‘draw’ with these Line Based Detail Components once in a project are similar to pulling lines around; with a few main differences:
1) Depending on how built these can add “offset” for more productivity… or nest these together to make one family satisfy any dynamic future need (we will cover this in a future posting).
2) When there is a fundamental change in a detail component all the other instances will change, in every detail, on every sheet… the Tags & Keynotes too!!! Thus we leverage one Power of BIM: Change it once and it changes everywhere.

The following step-by-step should be clear if you have a decent understanding of Revit Family Creation.

Making a Line Based Detail Component

1) Using the Big “R”, at the top/left of Revit (AKA: the Application Button) choose the flyout arrow next to NEW, then choose FAMILY.

2) Select the Detail Component line based template (Image 2).

3) Create a line in the new family.

-there, I said it… my rule is technically broken if you are thinking how I usually think…though in this case I am not being that literal (ahh, the contradictions of communication).

4) Lock it to the REF PLANES (Image 3).

Image 3

5) Flex the length
If all is working then move on, if not try again…

6) Save the family (use a good naming convention & library location, right? But you knew that…).

OK ready for the proof? Here we go…

These 4 details (Image 4) are the same, right? Not really… one uses lines, the other three share a Detail Component of the line based variety…



Image 4 (Looks can be deceiving)

In the next image there is a change to the Detail Component from being “Bituminous Sheet Waterproofing” to “6 Mil. Polyethylene”… Note the text becomes instantly wrong… in a lot of places…









Image 5 (Change can be great)

Now extrapolate this type of change out to the multitude of components in the numerous details you may have and you can probably see the benefit of taking a little extra time up-front to find and create your Detail Components (line based or otherwise), AS DETAIL COMPONENTS for every specific case necessary… Word to the wise: If you have never looked at how many detail components there are in the OOTB Revit library, go bounce there asap!

Again, Revit is not a drafting software.

Happy Detailing!!



Written by Kris Lengieza

Tips and Tricks for implementing technology at your organization

As the use of technology is becoming more and more prevalent in the construction industry you may be asking yourself how you can implement such a huge change in your organization effectively. With more than 70% of change initiatives failing to take hold, how do you avoid falling into that majority? Here are some tips and tricks to help ensure that you are primed for success.

Read More
Kelar Pacific Autodesk University 2017
Written by Kelar Pacific

Autodesk University 2017 – What to look for in 2018

The BIG Picture – Autodesk® Forge, the Development Platform for the Future

Autodesk University (AU) 2017 highlighted Autodesk® Forge as the proven foundation for creating connective technology.

With Forge API resources, the AEC industry is no longer limited by multiple product silos. Now, everyone can develop custom applications and create connected workflows to reduce repetitive tasks and improve project insight.

Read More
Autodesk Desktop Connector - Kelar Pacific
Written by Ehsan Yazdjerdi

4 Ways Autodesk Desktop Connector Improves AEC Cloud Collaboration Workflows

Autodesk provides numerous cloud-based solutions to the Architecture, Engineering, and Construction (AEC) industry facilitating collaboration between project teams throughout the project lifecycle. One  solution is BIM 360 Team, a project-centric tool intended to overcome the multidiscipline collaboration challenges during the design and development phase of a project.

Read More
BIM Levels of Development - Kelar Pacific
Written by Kelar Pacific

Construction Design Phases vs BIM Levels of Development – Part 4 of 4

What is considered the industry standard of LODs?

Today, there is no official LOD Standard, or a requirement for one in the U.S.  Several organizations are providing LOD Specification Workbooks to help with the adoption effort.  These organizations include:

Any given project should follow the standard being used by the client and the designer.

To conclude the 4 part topic of Construction Design Phases vs BIM Levels of Development, confirm the following prior to starting on any project:

  1. Is the project governed by Design Phases or BIM LODs?
  2. If governed by BIM LODs, are the BIM files available for contractor use?
    If BIM files are available, be specific about requesting the file types needed.

    • Consider Autodesk’s Navisworks as an industry standard for reviewing and extracting quantities and other data. Typically Navisworks file formats (*.nwd) are sufficient.
    • The Navisworks Simulate software would likely be the minimum requirement for design simulation and project review.
  3. Is there an LOD Specification Workbook?
    • If so, is it available for contractors use?
    • Is the contractor bound to the LODs for their cost proposals for each defined portion of work?
  4. Is there a contractual agreement between the Owner/Client and the Architect/Designer that is defined around the LODs the prime contractor, and their subcontractors, may also be bound to?
  5. What is the prime contractor’s cost estimating expectations for each of the various subcontractors? And, will there be different LODs for each trade?
  6. Bottom line, be sure you are clear about how a project is defined and measured for progress and completeness by confirming the use of “Construction Design Phases,” OR “BIM Levels of Development.”
